HB 1575 Bi-Fold Flush Pull

The HB 1575 Bi-Fold Flush Pull by Halliday Baillie is a solid brass flush pull sized for pivot or bifold doors on a grand scale. Concealed fixing with no exposed screw fasteners. The increased finger grip provides efficient leverage for oversized doors. This flush pull is handed — specify LH or RH when ordering.

Sold individually. For double-sided use, install one pull on each side. If installing on a pocket door, pair with the HB 680 Push Button Edge Pull. Made in New Zealand.

Specifications

• Dimensions: L 510 mm (20") x W 70 mm (2.75") x D 17 mm (0.67")
• Internal grip depth: 14 mm (0.55")
• Minimum door thickness: 36 mm (1.4") back-to-back, 45 mm (1.8") with end pulls
• Suitable for wood or aluminium doors
• Handed: specify LH or RH

Glue, epoxy, or silicone products are not required or recommended for installation.

Materials

Solid brass.

Available Finishes

• SC: Satin Chrome
• PC: Polished Chrome
• BN: Brushed Nickel
• PB: Polished Brass
• WHT: Powder Coat White
• EBA: Powder Coat Electro Black Ace
• EMB: Powder Coat Electro Medium Bronze
• EDB: Powder Coat Electro Dark Bronze

See full Halliday Baillie Finish Guide.

Product Downloads

• HB 1575 Product Sheet (PDF)
• HB Full Catalogue (PDF)
