Charlie Bar Door Pull

The Charlie Bar Door Pull by CBH is a round bar door pull with a classic geometric form. Available in custom lengths and back-to-back mounting configurations for wood, metal, and glass doors.

Explore the full Charlie Collection. Made in Canada.

Specifications

• Dimensions: Ø 25 mm (1") x D 45 mm (1.75") x L 457 mm (18")
• Centre to Centre: 305 mm (12")

Mounting Options

• Single Pull — Single-sided wood or metal door: 44 mm (1-3/4") thickness
• Double Pull — Back-to-back wood or metal door: 44 mm (1-3/4") thickness
• Single Pull — Single-sided glass door: 13 mm (1/2") glass thickness
• Double Pull — Back-to-back glass door: 9.5 mm (3/8") – 12.7 mm (1/2") glass thickness

Glass Hole Prep: Hole cannot be less than the thickness of the glass. Glass should typically be prepped at 1/2" or 5/8" — the included washer covers the hole and serves as a stop for the mounting bolt.

Custom lengths and back-to-back options available — contact us. Mounting hardware included.

Materials

Stainless steel or brass.

Available Finishes

• Satin Stainless Steel
• Polished Stainless Steel
• Satin Chrome
• Polished Chrome
• Satin Aluminum
• Satin Nickel
• Polished Nickel
• Lacquered Satin Brass
• Unlacquered Satin Brass
• Lacquered Polished Brass
• Unlacquered Polished Brass
• Satin Bronze
• Polished Bronze
• Oxidized Bronze
• Antique Brass
• Antique Bronze
• Antique Nickel
• Antique Copper
• Gloss White
• Matte Black
• Ivory
• Custom finishes available upon request, including antimicrobial clear coating

Material Notes

• Antique and oxidized finishes are hand-applied, resulting in unique, organic surface variations.
• Lacquered finishes maintain a consistent appearance over time. Unlacquered finishes will naturally age and develop a patina.
• Most finishes are lacquered by default. Satin Nickel, Satin Chrome, and Satin Stainless Steel are unlacquered. Oxidized Bronze is lacquered unless requested otherwise.
• See the Care & Maintenance Guide.

Product Downloads

N/A
